Demystifying 5G – 5G New Radio (NR) waveform generation

Demystifying 5G – 5G New Radio (NR) waveform generation

How to generate a 5G New Radio (NR) waveform? This video demonstrates the generation of a 5G NR waveform using the R&S®SMW200A vector signal generator and the R&S®SMW-K114 5G air interface candidates option from Rohde & Schwarz. In this example the 5G waveform uses one of the physical layer parameterization currently discussed in 3GPP RAN1.

The demystifying 5G video series discusses main topics related to 5G including requirements, timeline, potential frequency and waveform candidates.
