R&S®ZNA Vector network analyzers

Key Facts

10 MHz to 26.5/43.5/50/67 GHz (R&S®ZNA26/43/50/67) 10 MHz to 110 GHz (R&S®ZNA67EXT)
Two or four port models available
Excellent RF-performance
Up to four integrated sources
Unique and intuitive touch-only operation

Richiedi un preventivo Configure your product

Masters the most challenging measurement tasks

The R&S®ZNA vector network analyzers are the high-end series in the Rohde & Schwarz VNA portfolio: excellent RF-performance is combined with a wide range of software features and a unique hardware concept. The touch-only operation together with the DUT-centric approach makes the R&S®ZNA a powerful, universal and compact measurement system for characterizing passive and active devices.

Quick Links

Available Models
Available Options
Show all Downloads

Features & benefits

Excellent RF-performance

High performance and fast speed for advanced measurement tasks

Precise measurements on active and passive components
Wide dynamic range to characterize even high-blocking devices under test
Excellent stability, low trace noise and outstanding raw system data for high reliability
High accuracy suitable also for metrology applications
Wide power sweep range

**R&S®ZNA43 with four ports and direct channel access**

Versatile hardware options

Powerful and universal measurement system

Optional direct channel access for wide dynamic range, external test setups and system integration
Up to four internal phase-coherent sources for high flexibility and short sweep times
Up to two internal receiver LOs for fast mixer measurements with low trace noise
Up to eight independent receivers for reliable multi-channel phase measurements
Up to four internal pulse modulators and pulse generators
Optional source and receiver step attenuators for expanding the usable power range

Wide range of software options

Challenging measurements configured intuitively

Time domain analysis and extended features such as eye diagrams for signal integrity
Scalar mixer measurements and frequency converting measurements
Vector mixer measurements for advanced mixer measurements
Frequency converting measurements on mixers/converters without LO access
Spectrum analysis mode for an extensive analysis of the device under test
Real-time measurement uncertainty calculation plus verification measurement (METAS VNA Tools)

Unique operational concept

Intuitive touch-based operation with sophisticated user interface

Two independent touchscreens for convenient operation
Display of user-selected content (e.g. SCPI commands) on smaller screen possible
Efficient operation with multi-touch gestures
Free drag-and-drop configuration of channels and diagrams
DUT-centric approach adapts to user requirements and optimizes settings
Extensive evaluation features for detailed analysis of measurement traces

Extension units

Advanced measurement capabilities

Frequency extension up to 1.1 THz with the R&S®ZVA-Z and R&S®ZC converter families.

Accessories for a complete solution

Different accessories for calibration, verification and measurements

Mechanical calibration and verification kits
Automatic calibration units
Inline calibration units for in-situ refresh of calibration data
Test cables
Torque wrenches
Support of R&S®NRP power sensor family

**Automatic calibration unit, power sensor and calibration mixer.**

Available models

Available options

Direct channel and signal path access

Product

Descrizione

R&S®ZNA-B26

Order Number 1332.4598.02

Descrizione

Direct IF access

R&S®ZNA26-B16

Order Number 1332.4581.22

Descrizione

Direct source and receiver access

for R&S®ZNA26 (2 ports)

R&S®ZNA26-B16

Order Number 1332.4581.24

Descrizione

Direct source and receiver access

for R&S®ZNA26 (4 ports)

R&S®ZNA26-B161

Order Number 1332.4823.51

Descrizione

Direct source monitor access, port 1

for R&S®ZNA26 (HW opt.)

R&S®ZNA26-B163

Order Number 1332.4823.53

Descrizione

Direct source monitor access, port 1+3

for R&S®ZNA26 (HW opt.)

R&S®ZNA43-B16

Order Number 1332.4581.42

Descrizione

Direct source and receiver access

for R&S®ZNA43 (2 ports)

R&S®ZNA43-B16

Order Number 1332.4581.44

Descrizione

Direct source and receiver access

for R&S®ZNA43 (4 ports)

R&S®ZNA43-B161

Order Number 1332.4830.51

Descrizione

Direct source monitor access, port 1

for R&S®ZNA43 (HW opt.)

R&S®ZNA43-B163

Order Number 1332.4830.53

Descrizione

Direct source monitor access, port 1+3

for R&S®ZNA43 (HW opt.)

R&S®ZNA50-B16

Order Number 1332.6278.52

Descrizione

Direct source and receiver accesss

for R&S®ZNA50 (2 ports)

R&S®ZNA50-B16

Order Number 1332.6278.54

Descrizione

Direct source and receiver accesss

for R&S®ZNA50 (4 ports)

R&S®ZNA67-B16

Order Number 1332.6278.62

Descrizione

Direct source and receiver accesss

for R&S®ZNA67 (2 ports)

R&S®ZNA67-B16

Order Number 1332.6278.64

Descrizione

Direct source and receiver accesss

for R&S®ZNA67 (4 ports)

R&S®ZNA50-B161

Order Number 1332.5107.51

Descrizione

R&S®ZNA50-B161 SRC MONITOR P1

Direct source monitor access for port 1
before the source step attenuator
for R&S®ZNA50

R&S®ZNA50-B163

Order Number 1332.5107.53

Descrizione

R&S®ZNA50-B163 SRC MONITOR ACCESS P1+P3

Direct source monitor access for port 1 and port 3
before the source step attenuator
for R&S®ZNA50 (4 ports)

R&S®ZNA67-B161

Order Number 1332.5113.51

Descrizione

R&S®ZNA67-B161 SRC MONITOR ACCESS P1

Direct source monitor access for port 1
before the source step attenuator
for R&S®ZNA67

R&S®ZNA67-B163

Order Number 1332.5113.53

Descrizione

R&S®ZNA67-B163 SRC MONITOR ACCESS P1+P3

Direct source monitor access for port 1 and port 3
before the source step attenuator
for R&S®ZNA67 (4 ports)

Source step attenuators

Product

Descrizione

R&S®ZNA26-B21

Order Number 1332.4630.21

Descrizione

Source step attenuator for port 1

mechanical, 70 dB in 10 dB steps, for R&S®ZNA26

R&S®ZNA26-B22

Order Number 1332.4630.22

Descrizione

Source step attenuator for port 2

mechanical, 70 dB in 10 dB steps, for R&S®ZNA26

R&S®ZNA26-B23

Order Number 1332.4630.23

Descrizione

Source step attenuator for port 3

mechanical, 70 dB in 10 dB steps, for R&S®ZNA26

R&S®ZNA26-B24

Order Number 1332.4630.24

Descrizione

Source step attenuator for port 4

mechanical, 70 dB in 10 dB steps, for R&S®ZNA26

R&S®ZNA43-B21

Order Number 1332.4646.21

Descrizione

Source step attenuator for port 1

mechanical, 70 dB in 10 dB steps, for R&S®ZNA43

R&S®ZNA43-B22

Order Number 1332.4646.22

Descrizione

Source step attenuator for port 2

mechanical, 70 dB in 10 dB steps, for R&S®ZNA43

R&S®ZNA43-B23

Order Number 1332.4646.23

Descrizione

Source step attenuator for port 3

mechanical, 70 dB in 10 dB steps, for R&S®ZNA43

R&S®ZNA43-B24

Order Number 1332.4646.24

Descrizione

Source step attenuator for port 4

mechanical, 70 dB in 10 dB steps, for R&S®ZNA43

R&S®ZNA50-B21

Order Number 1332.5188.21

Descrizione

Source step attenuator for port 1

mechanical, 50dB in 10dB steps, for R&S®ZNA50

R&S®ZNA50-B22

Order Number 1332.5188.22

Descrizione

Source step attenuator for port 2

mechanical, 50dB in 10dB steps, for R&S®ZNA50

R&S®ZNA50-B23

Order Number 1332.5188.23

Descrizione

Source step attenuator for port 3

mechanical, 50dB in 10dB steps, for R&S®ZNA50

R&S®ZNA50-B24

Order Number 1332.5188.24

Descrizione

Source step attenuator for port 4

mechanical, 50dB in 10dB steps, for R&S®ZNA50

R&S®ZNA67-B21

Order Number 1332.5194.21

Descrizione

Source step attenuator for port 1

mechanical, 50dB in 10dB steps, for R&S®ZNA67

R&S®ZNA67-B22

Order Number 1332.5194.22

Descrizione

Source step attenuator for port 2

mechanical, 50dB in 10dB steps, for R&S®ZNA67

R&S®ZNA67-B23

Order Number 1332.5194.23

Descrizione

Source step attenuator for port 3

mechanical, 50dB in 10dB steps, for R&S®ZNA67

R&S®ZNA67-B24

Order Number 1332.5194.24

Descrizione

Source step attenuator for port 4

mechanical, 50dB in 10dB steps, for R&S®ZNA67

R&S®ZNA67-B21

Order Number 1332.5013.21

Descrizione

R&S®ZNA67-B21 GEN. STEP ATTENUATOR P1

Source step attenuator for port 1,
mechanical, 50 dB in 10 dB steps
for R&S®ZNA67

R&S®ZNA67-B22

Order Number 1332.5013.22

Descrizione

R&S®ZNA67-B22 GEN. STEP ATTENUATOR P2

Source step attenuator for port 2,
mechanical, 50 dB in 10 dB steps
for R&S®ZNA67

R&S®ZNA67-B23

Order Number 1332.5013.23

Descrizione

R&S®ZNA67-B23 GEN. STEP ATTENUATOR P3

Source step attenuator for port 3,
mechanical, 50 dB in 10 dB steps
for R&S®ZNA67

R&S®ZNA67-B24

Order Number 1332.5013.24

Descrizione

R&S®ZNA67-B24 GEN. STEP ATTENUATOR P4

Source step attenuator for port 4,
mechanical, 50 dB in 10 dB steps
for R&S®ZNA67

R&S®ZNA50-B21

Order Number 1332.5007.21

Descrizione

R&S®ZNA50-B21 GEN. STEP ATTENUATOR P1

Generator step attenuator port 1,
mechanical, 70 dB in steps of 10 dB
for R&S®ZNA50

R&S®ZNA50-B22

Order Number 1332.5007.22

Descrizione

R&S®ZNA50-B22 GEN. STEP ATTENUATOR P2

Generator step attenuator port 2,
mechanical, 70 dB in steps of 10 dB
for R&S®ZNA50

R&S®ZNA50-B23

Order Number 1332.5007.23

Descrizione

R&S®ZNA50-B23 GEN. STEP ATTENUATOR P3

Generator step attenuator port 3,
mechanical, 70 dB in steps of 10 dB
for R&S®ZNA50

R&S®ZNA50-B24

Order Number 1332.5007.24

Descrizione

R&S®ZNA50-B24 GEN. STEP ATTENUATOR P4

Generator step attenuator port 4,
mechanical, 70 dB in steps of 10 dB
for R&S®ZNA50

Receiver step attenuators

Product

Descrizione

R&S®ZNA26-B31

Order Number 1332.4700.31

Descrizione

Receiver step attenuator for port 1

mechanical, 35 dB in 5 dB steps, for R&S®ZNA26

R&S®ZNA26-B32

Order Number 1332.4700.32

Descrizione

Receiver step attenuator for port 2

mechanical, 35 dB in 5 dB steps, for R&S®ZNA26

R&S®ZNA26-B33

Order Number 1332.4700.33

Descrizione

Receiver step attenuator for port 3

mechanical, 35 dB in 5 dB steps, for R&S®ZNA26 (4 ports)

R&S®ZNA26-B34

Order Number 1332.4700.34

Descrizione

Receiver step attenuator for port 4

mechanical, 35 dB in 5 dB steps, for R&S®ZNA26 (4 ports)

R&S®ZNA43-B31

Order Number 1332.4717.31

Descrizione

Receiver step attenuator for port 1

mechanical, 35 dB in 5 dB steps, for R&S®ZNA43

R&S®ZNA43-B32

Order Number 1332.4717.32

Descrizione

Receiver step attenuator for port 2

mechanical, 35 dB in 5 dB steps, for R&S®ZNA43

R&S®ZNA43-B33

Order Number 1332.4717.33

Descrizione

Receiver step attenuator for port 3

mechanical, 35 dB in 5 dB steps, for R&S®ZNA43 (4 ports)

R&S®ZNA43-B34

Order Number 1332.4717.34

Descrizione

Receiver step attenuator for port 4

mechanical, 35 dB in 5 dB steps, for R&S®ZNA43 (4 ports)

R&S®ZNA50-B31

Order Number 1332.5165.31

Descrizione

Receiver step attenuator for port 1

mechanical, 35dB in 5dB steps, for R&S®ZNA50

R&S®ZNA50-B32

Order Number 1332.5165.32

Descrizione

Receiver step attenuator for port 2

mechanical, 35dB in 5dB steps, for R&S®ZNA50

R&S®ZNA50-B33

Order Number 1332.5165.33

Descrizione

Receiver step attenuator for port 3

mechanical, 35dB in 5dB steps, for R&S®ZNA50

R&S®ZNA50-B34

Order Number 1332.5165.34

Descrizione

Receiver step attenuator for port 4

mechanical, 35dB in 5dB steps, for R&S®ZNA50

R&S®ZNA67-B31

Order Number 1332.5171.31

Descrizione

Receiver step attenuator for port 1

mechanical, 35dB in 5dB steps, for R&S®ZNA67

R&S®ZNA67-B32

Order Number 1332.5171.32

Descrizione

Receiver step attenuator for port 2

mechanical, 35dB in 5dB steps, for R&S®ZNA67

R&S®ZNA67-B33

Order Number 1332.5171.33

Descrizione

Receiver step attenuator for port 3

mechanical, 35dB in 5dB steps, for R&S®ZNA67

R&S®ZNA67-B34

Order Number 1332.5171.34

Descrizione

Receiver step attenuator for port 4

mechanical, 35dB in 5dB steps, for R&S®ZNA67

R&S®ZNA50-B31

Order Number 1332.5020.31

Descrizione

Receiver step attenuator for port 1

mechanical, 35dB in 5dB steps, for R&S®ZNA50

R&S®ZNA50-B32

Order Number 1332.5020.32

Descrizione

Receiver step attenuator for port 2

mechanical, 35dB in 5dB steps, for R&S®ZNA50

R&S®ZNA50-B33

Order Number 1332.5020.33

Descrizione

Receiver step attenuator for port 3

mechanical, 35dB in 5dB steps, for R&S®ZNA50

R&S®ZNA50-B34

Order Number 1332.5020.34

Descrizione

Receiver step attenuator for port 4

mechanical, 35dB in 5dB steps, for R&S®ZNA50

R&S®ZNA67-B31

Order Number 1332.5036.31

Descrizione

R&S®ZNA67-B31 REC. STEP ATTENUATOR P1

Receiver step attenuator for port 1,
mechanical, 35 dB in 5 dB steps
for R&S®ZNA67

R&S®ZNA67-B32

Order Number 1332.5036.32

Descrizione

R&S®ZNA67-B32 REC. STEP ATTENUATOR P2

Receiver step attenuator for port 2,
mechanical, 35 dB in 5 dB steps
for R&S®ZNA67

R&S®ZNA67-B33

Order Number 1332.5036.33

Descrizione

R&S®ZNA67-B33 REC. STEP ATTENUATOR P3

Receiver step attenuator for port 3,
mechanical, 35 dB in 5 dB steps
for R&S®ZNA67

R&S®ZNA67-B34

Order Number 1332.5036.34

Descrizione

R&S®ZNA67-B34 REC. STEP ATTENUATOR P4

Receiver step attenuator for port 4,
mechanical, 35 dB in 5 dB steps
for R&S®ZNA67

Internal sources

Product

Descrizione

R&S®ZNA-B5

Order Number 1332.4675.02

Descrizione

2^nd internal LO source

for R&S®ZNA (4 ports)

R&S®ZNA-B8

Order Number 1332.4652.02

Descrizione

mmWave converter LO

10 MHz to 26.5 GHz

R&S®ZNA26-B3

Order Number 1332.4523.02

Descrizione

3^rd and 4^th internal source

for R&S®ZNA26 (4 ports)

R&S®ZNA43-B3

Order Number 1332.4617.02

Descrizione

3^rd and 4^th internal source

for R&S®ZNA43 (4 ports)

R&S®ZNA50-B3

Order Number 1332.4981.02

Descrizione

3^rd and 4^th internal source

for R&S®ZNA50 (4 ports)

R&S®ZNA67-B3

Order Number 1332.4998.02

Descrizione

3^rd and 4^th internal source

for R&S®ZNA67 (4 ports)

R&S®ZNA26-B52

Order Number 1332.6503.02

Descrizione

2nd LO+RF source for R&S®ZNA26 (2 ports) (HW opt)

2nd RF and 2nd internal LO source, for R&S®ZNA26 (2 port models). (External access to the LO src (up to 26.5 GHz) requires option R&S®ZNA-B8). (Hardware option)

R&S®ZNA43-B52

Order Number 1332.6510.02

Descrizione

2nd LO+RF source for R&S®ZNA43 (2 ports) (HW opt)

2nd RF and 2nd internal LO source, for R&S®ZNA43 (2 port models). (External access to the LO src (up to 26.5 GHz) requires option R&S®ZNA-B8). (Hardware option)

R&S®ZNA50-B52

Order Number 1332.6526.02

Descrizione

R&S®ZNA50-B52 2ND SRC+INT LO (2P ZNA)

2nd RF and 2nd internal LO source,
for R&S®ZNA50 (2 port models).

R&S®ZNA67-B52

Order Number 1332.6532.02

Descrizione

R&S®ZNA67-B52 2ND SRC+INT LO (2P ZNA)

2nd RF and 2nd internal LO source,
for R&S®ZNA67 (2 port models)

Signal conditioning

Product

Descrizione

R&S®ZNA26-B41

Order Number 1332.4775.41

Descrizione

Internal pulse modulators for port 1

for R&S®ZNA26

R&S®ZNA26-B42

Order Number 1332.4775.42

Descrizione

Internal pulse modulators for port 2

for R&S®ZNA26

R&S®ZNA26-B43

Order Number 1332.4775.43

Descrizione

Internal pulse modulators for port 3

for R&S®ZNA26 (4 ports)

R&S®ZNA26-B44

Order Number 1332.4775.44

Descrizione

Internal pulse modulators for port 4

for R&S®ZNA26 (4 ports)

R&S®ZNA26-B213

Order Number 1332.4846.13

Descrizione

Internal combiner, port 1 and port 3

for R&S®ZNA26 (HW opt)

R&S®ZNA26-B302

Order Number 1332.4752.12

Descrizione

Low-noise preamplifier at receiver, port 2, for R&S®ZNA26

R&S®ZNA26-B501

Order Number 1332.5220.11

Descrizione

Low-power spurious reduction, port 1, for R&S®ZNA26

R&S®ZNA43-B41

Order Number 1332.4781.41

Descrizione

Internal pulse modulators for port 1

for R&S®ZNA43

R&S®ZNA43-B42

Order Number 1332.4781.42

Descrizione

Internal pulse modulators for port 2

for R&S®ZNA43

R&S®ZNA43-B43

Order Number 1332.4781.43

Descrizione

Internal pulse modulators for port 3

for R&S®ZNA43 (4 ports)

R&S®ZNA43-B44

Order Number 1332.4781.44

Descrizione

Internal pulse modulators for port 4

for R&S®ZNA43 (4 ports)

R&S®ZNA43-B213

Order Number 1332.4869.13

Descrizione

Internal combiner, port 1 and port 3

for R&S®ZNA43 (HW opt)

R&S®ZNA43-B501

Order Number 1332.5236.11

Descrizione

Low-power spurious reduction, port 1, for R&S®ZNA43

R&S®ZNA50-B41

Order Number 1332.5088.41

Descrizione

Internal Pulse Modulator for port 1

for R&S®ZNA50

R&S®ZNA50-B42

Order Number 1332.5088.42

Descrizione

Internal Pulse Modulator for port 2

for R&S®ZNA50

R&S®ZNA50-B43

Order Number 1332.5088.43

Descrizione

Internal Pulse Modulator for port 3

for R&S®ZNA50

R&S®ZNA50-B44

Order Number 1332.5088.44

Descrizione

Internal Pulse Modulator for port 4

for R&S®ZNA50

R&S®ZNA67-B41

Order Number 1332.5094.41

Descrizione

Internal Pulse Modulator for port 1

for R&S®ZNA67

R&S®ZNA67-B42

Order Number 1332.5094.42

Descrizione

Internal Pulse Modulator for port 2

for R&S®ZNA67

R&S®ZNA67-B43

Order Number 1332.5094.43

Descrizione

Internal Pulse Modulator for port 3

for R&S®ZNA67

R&S®ZNA67-B44

Order Number 1332.5094.44

Descrizione

Internal Pulse Modulator for port 4

for R&S®ZNA67

R&S®ZNA43-B302

Order Number 1332.4769.22

Descrizione

Low noise pre-amplifier receiver port 2 (R&S®ZNA43)

Low noise pre-amplifier at receiver port 2, up to 43.5 GHz for R&S®ZNA43. (requires R&S®ZNA43-B16, R&S®ZNA43-B32)

R&S®ZNA26-B212

Order Number 1332.5265.02

Descrizione

Internal combiner for the R&S®ZNA26 model (*.22) with 2 test ports (hardware option)

Provides a two tone signal at Port 1, combining the internal sources of Port 1 and Port 2 (requires the R&S®ZNA26-B52, R&S®ZNA26-B21)

R&S®ZNA43-B212

Order Number 1332.5271.02

Descrizione

Internal combiner for the R&S®ZNA43 models (*.42, *.43) with 2 test ports (hardware opt)

Provides a two tone signal at Port 1, combining the internal sources of Port 1 and Port 2 (requires the R&S®ZNA43-B52, R&S®ZNA43-B21)

R&S®ZNA50-B212

Order Number 1332.5288.02

Descrizione

R&S®ZNA50-B212 INTERNAL COMBINER P1-P2

Internal combiner
for R&S®ZNA50 (2 ports).
Provides a two-tone signal at Port 1

R&S®ZNA50-B213

Order Number 1332.5042.13

Descrizione

R&S®ZNA50-B213 INTERNER COMBINER P1-P3

Internal combiner
for port 1 and port 3
for R&S®ZNA50 (4 ports)
Provides a two-tone signal at Port 1

R&S®ZNA50-B302

Order Number 1332.4798.12

Descrizione

R&S®ZNA50-B302 LOW NOISE AMP. REC P2

Low noise preamplifier at receiver
port 2, for R&S®ZNA50.;
(requires R&S®ZNA50-B16, R&S®ZNA50-B32);
export restricted

R&S®ZNA50-B312

Order Number 1332.5659.02

Descrizione

R&S®ZNA50-B312 LOW NOISE AMP. REC P2

Low noise preamplifier at receiver
port 2, for R&S®ZNA50.;
combination with R&S®ZNA-K1 not possible
no export restriction

R&S®ZNA50-B501

Order Number 1332.5242.11

Descrizione

R&S®ZNA50-B501 LOW POWER SPUR REDUCTION

Spur magnitude reduction for enhanced
spectral purity with low RF output
power, for Port 1
export restricted

R&S®ZNA50-B511

Order Number 1332.5671.02

Descrizione

R&S®ZNA50-B511 LOW POWER SPUR REDUCTION

Spur magnitude reduction for enhanced
spectral purity with low RF output
power, for Port 1
no export restriction

R&S®ZNA67-B212

Order Number 1332.5294.02

Descrizione

R&S®ZNA67-B212 INTERNALCOMBINER P1-P2

Internal combiner
for R&S®ZNA67 (2 ports).
Provides a two-tone signal at Port 1

R&S®ZNA67-B213

Order Number 1332.5065.13

Descrizione

R&S®ZNA67-B213 INTERNAL COMBINER P1-P3

Internal combiner
for port 1 and port 3
for R&S®ZNA67 (4 ports)
Provides a two-tone signal at Port 1

R&S®ZNA67-B302

Order Number 1332.4817.12

Descrizione

R&S®ZNA67-B302 LOW NOISE AMP. REC P2

Low noise pre-amplifier at receiver
port 2, for R&S®ZNA67

R&S®ZNA67-B312

Order Number 1332.5665.02

Descrizione

R&S®ZNA67-B312 LOW NOISE AMP. REC P2

Low noise pre-amplifier at receiver
port 2, for R&S®ZNA67

R&S®ZNA67-B501

Order Number 1332.5259.11

Descrizione

R&S®ZNA67-B501 LOW POWER SPUR REDUCTION

Spur magnitude reduction for enhanced
spectral purity with low RF output
power, for Port 1

R&S®ZNA67-B511

Order Number 1332.5688.02

Descrizione

R&S®ZNA67-B511 LOW POWER SPUR REDUCTION

Spur magnitude reduction for enhanced
spectral purity with low RF output
power, for Port 1

Other

Product

Descrizione

R&S®ZNA-B4

Order Number 1332.4530.02

Descrizione

Precision frequency reference

for R&S®ZNA

R&S®ZNA-B7

Order Number 1332.4546.02

Descrizione

Memory extension

for multiple receiver pulse profile measurement

R&S®ZNA-B19

Order Number 1332.4600.02

Descrizione

Additional removable harddisc

for R&S®ZNA

R&S®ZNA-B91

Order Number 1332.4800.02

Descrizione

Trigger and control I/O board

for R&S®ZNA

R&S®ZZA-KN6

Order Number 1175.3056.00

Descrizione

19" adapter BW2010, cabinet 6HU 1/1

R&S®ZNA26-Z9

Order Number 1332.4730.26

Descrizione

Cable Set for ZNA-K9 for R&S®ZNA26 (4 ports)

Combines signals from port 1 and port 3 to a two-tone signal at port 1 (for Intermodulation and two-tone mixer Group Delay measurements)

R&S®ZNA26-U16

Order Number 1332.6410.22

Descrizione

Direct source and receiver access

for R&S®ZNA26 (2 ports) (HW opt.)

R&S®ZNA26-U16

Order Number 1332.6410.24

Descrizione

Direct source and receiver access

for R&S®ZNA26 (4 ports) (HW opt.)

R&S®ZNA26-U21

Order Number 1332.6426.21

Descrizione

Source step att., port 1, 70 dB

for R&S®ZNA26 (HW opt.)

R&S®ZNA26-U22

Order Number 1332.6426.22

Descrizione

Source step att., port 2, 70 dB

for R&S®ZNA26 (HW opt.)

R&S®ZNA26-U23

Order Number 1332.6426.23

Descrizione

Source step att., port 3, 70 dB

for R&S®ZNA26 (HW opt.)

R&S®ZNA26-U24

Order Number 1332.6426.24

Descrizione

Source step att., port 4, 70 dB

for R&S®ZNA26 (HW opt.)

R&S®ZNA26-U31

Order Number 1332.6461.31

Descrizione

Receiver step att., port 1, 35 dB

for R&S®ZNA26 (HW opt.)

R&S®ZNA26-U32

Order Number 1332.6461.32

Descrizione

Receiver step att., port 2, 35 dB

for R&S®ZNA26 (HW opt.)

R&S®ZNA26-U33

Order Number 1332.6461.33

Descrizione

Receiver step att., port 3, 35dB

for R&S®ZNA26 (HW opt.)

R&S®ZNA26-U34

Order Number 1332.6461.34

Descrizione

Receiver step att., port 4, 35dB

for R&S®ZNA26 (HW opt.)

R&S®ZNA26-U161

Order Number 1332.6184.51

Descrizione

Direct source monitor access, port 1

for R&S®ZNA26 (HW opt.)

R&S®ZNA26-U163

Order Number 1332.6184.53

Descrizione

Direct source monitor access, port 1+3

for R&S®ZNA26 (HW opt.)

R&S®ZNA43-Z9

Order Number 1332.4730.43

Descrizione

Cable Set for ZNA-K9 for R&S®ZNA43 (4 ports), 2.92mm(m) connectors

Combines signals from port 1 and port 3 to a two-tone signal at port 1 (for Intermodulation and two-tone mixer Group Delay measurements)

R&S®ZNA43-Z9

Order Number 1332.4730.44

Descrizione

Cable Set for ZNA-K9 for R&S®ZNA43 (4 ports), 2.4mm(m) connectors

Combines signals from port 1 and port 3 to a two-tone signal at port 1 (for Intermodulation and two-tone mixer Group Delay measurements)

R&S®ZNA43-U16

Order Number 1332.6410.42

Descrizione

Direct source/receiver access

for R&S®ZNA43 (2 ports) (HW opt.)

R&S®ZNA43-U16

Order Number 1332.6410.44

Descrizione

Direct source/receiver access

for R&S®ZNA43 (4 ports) (HW opt.)

R&S®ZNA43-U21

Order Number 1332.6432.21

Descrizione

Source step att., port 1, 70 dB

for R&S®ZNA43 (HW opt.) Upgrade

R&S®ZNA43-U22

Order Number 1332.6432.22

Descrizione

Source step att., port 2, 70 dB

for R&S®ZNA43 (HW opt.) Upgrade

R&S®ZNA43-U23

Order Number 1332.6432.23

Descrizione

Source step att., port 3, 70 dB

for R&S®ZNA43 (HW opt.) Upgrade

R&S®ZNA43-U24

Order Number 1332.6432.24

Descrizione

Source step att., port 4, 70 dB

for R&S®ZNA43 (HW opt.) Upgrade

R&S®ZNA43-U31

Order Number 1332.6478.31

Descrizione

Receiver step att., port 1, 35 dB

for &S®ZNA43, (HW opt.) Upgrade

R&S®ZNA43-U32

Order Number 1332.6478.32

Descrizione

Receiver step att., port 2, 35 dB

for &S®ZNA43, (HW opt.) Upgrade

R&S®ZNA43-U33

Order Number 1332.6478.33

Descrizione

Receiver step att., port 3, 35 dB

for R&S®ZNA43, (HW opt.) Upgrade

R&S®ZNA43-U34

Order Number 1332.6478.34

Descrizione

Receiver step att., port 4, 35 dB

for R&S®ZNA43, (HW opt.) Upgrade

R&S®ZNA43-U161

Order Number 1332.6190.51

Descrizione

Direct source monitor access, port 1

for R&S®ZNA43 (HW opt.)

R&S®ZNA43-U163

Order Number 1332.6190.53

Descrizione

Direct source monitor access, port 1+3

for R&S®ZNA43 (HW opt.)

R&S®ZNA50-Z9

Order Number 1332.4730.50

Descrizione

Cable Set for ZNA-K9 for R&S®ZNA50 (4ports)

Combines signals from Port 1 and Port 3 to a two-tone signal at Port 1 (for IM and ZNA-K9 embedded LO GD measurements) for ZNA50, 4-port (2.4mm - 2.4mm)

R&S®ZNA67-Z9

Order Number 1332.4730.67

Descrizione

Cable Set for ZNA-K9 for R&S ZNA67 (4ports)

Combines signals from Port 1 and Port 3 to a two-tone signal at Port 1 (for IM and ZNA-K9 embedded LO GD measurements) for ZNA67, 4-port (1.85mm - 1.85mm)

R&S®ZNA43-U21

Order Number 1332.5307.21

Descrizione

Source step att., port 1, 70 dB
