Serial bus decoding. RTP - see the difference

Learn how to do low-speed serial bus decoding with the digital channels of the RTP

Teil 7/12

The 16 digital channels of the MSO option extend the measurement resources of the RTP. Use them for protocol-based triggering and decoding of low-speed interfaces such as I2C, SPI, MIL1553 or MIPI RFFE.
