Key facts
Starting at USD 5,890
The R&S®MXO 3 Series put big capabilities in a small package. Enjoy unmatched performance to quickly and easily gain expert understanding of your device under test . Powered by next-generation MXO technology the oscilloscope delivers fast and precise measurements in a small package.
Instantly see more signal detail with the world’s highest acquisition rate of up to 4.5 million waveforms per second and real-time signal capture of up to 99%.
Capture every detail with clarity and confidence thanks to 12-bit ADC resolution at all sample rates, enhanced 18-bit HD mode, advanced digital triggering and 125 Mpoints of standard memory, .
Save space without sacrificing usability: enjoy the brilliant 11.6" Full HD display and seamless integration into any setup with just 5U rack height across all models.
Unmatched performance in both time and frequency domain debugging and testing.
Quick links
See more signal details and subtle changes instantly
Using all 8 channels to see all details
Don't let anything get past you
Typical vertical resolution (left) vs. 18-bit HD Mode (right)
Get big capabilities in a surprisingly small package
Large 11.6" Full HD display in compact design
… with high-precision digital trigger
Flexible triggering with HD digital trigger
Fast and precise frequency domain measurements
Fast and precise frequency domain measurements
… with advanced usability designed for high productivity
Short learning curve with the R&S®MXO3
Get infinite oscilloscope trigger types with zone triggering
Infinite trigger types with zone triggering
Oscilloscope stays responsive, even with deep memory
Slow (left) vs. fast sample rate (right) with a long capture window
Order number 1335.2050.04
Order number 1335.2050.08
Order number 1335.2050P41
Order number 1335.2050P81
Order number 1335.2050P42
Order number 1335.2050P82
Order number 1335.2050P43
Order number 1335.2050P83
Order number 1335.2050P45
Order number 1335.2050P85
Order number 1335.2050P51
Order number 1335.2050P91
| Vertical system | ||
| Analog channels | 4, 8 | |
| Digital channels (opt.) | 16 | |
| Analog bandwidth (–3 dB) | 100 MHz, 200 MHz, 350 MHz, 500 MHz, 1 GHz | |
| Rise time | at 1 GHz bandwidth | < 350 ps |
| Input impedance | 50 Ω ± 1.5 %, 1 MΩ ± 1 % || 12 pF (meas.) |
|
| Input sensitivity | at 50 Ω | 1 mV/div to 1 V/div, support entire analog bandwidth |
| at 1 MΩ | 1 mV/div to 10 V/div, support entire analog bandwidth | |
| Vertical resolution | 12-bit ADC, up to 18-bit with HD mode (high definition) | |
| DC gain accuracy | input sensitivity > 5 mV/div input sensitivity ≤ 5 mV/div to ≥ 1 mV/div |
±1 % full scale ±1.5 % full scale |
| Channel-to-channel isolation | > 60 dB (1:1000) | |
| Acquisition system | ||
| Sampling rate | analog channels (real time) | max. 5 Gsample/s max. 2.5 Gsample all channels simultaneously |
| analog channels (interpolated) | max. 5 Tsample/s | |
| digital channels | max. 5 Gsample/s | |
| Acquisition memory | Standard | 125 Mpoints |
| Optional R&S®MXO3-B105 memory option | max. 500 Mpoints per channel | |
| History segments | 10k segments up to 1 million segments with option B105 |
|
| Max. acquisition rate | > 4 500 000 waveforms/s | |
| Acquisition modes | sample, peak detect, average, envelope | |
| Interpolation modes | linear, sin(x)/x, sample & hold | |
| Horizontal system | ||
| Timebase range | Selectable between 200 ps/div and 10 000 s/div | |
| Trigger system | ||
| Standard trigger types | Edge, glitch, width, runt, window, timeout, interval, slew rate, setup and hold, pattern, state trigger | |
| Advanced trigger modes | Zone trigger, A/B/R, serial bus, trigger in and out | |
| Trigger sensitivity | 0.0001 div, from DC to instrument bandwidth for all vertical scales |
|
| Analysis and measurement | ||
| Automatic measurements | >40 | |
| Cursor measurements | 4 | |
| Waveform mathematics | Up to 8 equations math on math (add, subtract, multiply, divide, absolute value, square, square root, integrate, differentiate, log10, loge, log2, reciprocal, invert, low pass, high pass, rescale (a*x+b)) | |
| General data | ||
| Dimensions | W × H × D | 375 mm × 233 mm × 163 mm (14.76 in × 9.17 in × 6.42 in) |
| Weight | without options, nominal | 4.0 kg (8.82 lb) |
| Rackmount height | 5 HU | |
| I/O Interfaces | Front | 2 × USB 3.1 Gen 1 ports, type A plug |
| Rear | 1 × USB 3.1 Gen 1 port, type B plug 1 × HDMI output 1 × RJ-45 connector, supports 10/100/1000BASE-T |
|
| Display | 11.6" LC TFT color display with capacitive touchscreen, resolution 1920 × 1080 pixel (Full HD) |
|
Order number 1335.2221.02
Bandwidth upgrade to 200 MHz for four-channel R&S®MXO 3 oscilloscopes
Order number 1335.2244.02
Bandwidth upgrade to 350 MHz for four-channel R&S®MXO 3 oscilloscopes
Order number 1335.2267.02
Bandwidth upgrade to 500 MHz for four-channel R&S®MXO 3 oscilloscopes
Order number 1335.2280.02
Bandwidth upgrade to 1 GHz for four-channel R&S®MXO 3 oscilloscopes
Order number 1335.2815.02
Bandwidth upgrade to 200 MHz for eight-channel R&S®MXO 3 oscilloscopes
Order number 1335.2821.02
Bandwidth upgrade to 350 MHz for 8-channel R&S®MXO 3 oscilloscopes
Order number 1335.2838.02
Bandwidth upgrade to 500 MHz for 8-channel R&S®MXO 3 oscilloscopes
Order number 1335.2844.02
Bandwidth upgrade to 1 GHz for 8-channel R&S®MXO 3 oscilloscopes
Order number 1335.2073.02
Mixed signal option for R&S®MXO 3 series with 16 digital channels
Order number 1335.2850.02
Arbitrary waveform generator, 50 MHz, 1 analog channel
Order number 1335.3105.02
Memory upgrade to 500 Mpts
Order number 1335.2867.02
Low speed serial protocol trigger and decode package: I2C, SPI, UART, RS-232/422/485, Quad-SPI, custom NRZ, custom Manchester
Order number 1335.2873.02
Automotive serial protocol trigger and decode package: CAN, CAN-FD, CAN-XL, LIN, SENT
Order number 1335.2996.02
Aerospace serial protocols trigger and decode package: ARINC 429, MIL-1553, SpaceWire
Order number 1335.2967.02
MIPI low-speed serial protocol trigger and decode package: SPMI, RFFE, I³C
Order number 1335.2973.02
Automotive ethernet trigger and decode package: 10BASE-T1S
Order number 1335.2880.02
Power analysis
Include - Harmonics, quality, efficiency, switching loss, safe operating area and turn on/off time measurement
Order number 1335.2896.02
Frequency response analysis/Bode plot (requires R&S®MXO3-B6 as source)
Order number 1335.2909.02
Application bundle with the following options: R&S®MXO3-B6, R&S®MXO3-B105, R&S®MXO3-K31, R&S®MXO3-K36, R;&S®MXO3-K510, R&S®MXO3-K520, R&S®MXO3-K530, R&S®MXO3-K550, R&S®MXO3-K560
Order number 1801.9005.02
R&S®ScopeStudio
PC offline software for R&S®MXO series oscilloscope
Order number 1804.8874.02
Serial bus option for R&S®ScopeStudio
I2C, I3C, SPI, UART/RS-232/RS-422/RS-485, CAN/CAN FD/CAN XL, LIN, ARINC429, MIL-STD-1553, SPMI, 10BASE-T1S, 100BASE-T1, QUAD-SPI, SpaceWire, SENT, RFFE, NRZ
Order number 1335.1902.02
Front cover to protect R&S®MXO 3 oscilloscope
Order number 1335.1919.02
Soft case for storing R&S®MXO 3 oscilloscope and accessories
Order number 1335.1925.02
Transit case protects R&S®MXO 3 oscilloscopes and accessories during transport
Order number 1335.2715.02
Rackmount adapter for MXO 3, 5 HU
Order number 1409.7550.00
Passive probe, 500 MHz, 10:1
Order number 1333.1370.02
Passive probe, 38 MHz, 1:1
Order number 1803.1599.02
700 MHz passive probe 25:1 with MMCX input
700 MHz passive probe 25:1 with MMCX input
Order number 1335.3005.02
300 MHz logic probe, 8 channels
Order number 1418.7007.02
Active single-ended probe, 1 GHz, Rohde & Schwarz probe interface
Order number 1410.3502.02
Active single-ended probe, 1.5 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface
Order number 1410.4715.02
Active differential probe, 1 GHz, Rohde & Schwarz probe interface
Order number 1410.4744.02
External attenuator
10:1, 2.0 GHz, 1.3 pF, 60 V DC, 42 V AC (peak) for R&S®RT-ZD20/30 probes. Included in R&S®RT-ZD10.
Order number 1410.4409.02
Active differential probe, 1.5 GHz, Rohde & Schwarz probe interface
Order number 1410.4609.02
Active differential probe, 3.0 GHz, Rohde & Schwarz probe interface
Order number 1800.5006.02
Power rail probe, 2 GHz, R&S®ProbeMeter, Rohde & Schwarz probe interface
2.0 GHz, 1:1, 50 kΩ, R&S probe interface
Order number 1333.0873.02
250 MHz passive high voltage probe
Order number 1409.7720.02
400 MHz passive high voltage probe
Order number 1409.7737.02
400 MHz passive high voltage probe
Order number 1800.2307.02
200 MHz High voltage differential probe
Order number 1800.2107.02
100 MHz High voltage differential probe
Order number 1800.2207.02
200 MHz High voltage differential probe
Order number 1800.2007.02
100 MHz High voltage differential probe
Order number 1804.5000.02
R&S®RT-ZISO base unit
Base unit to be configured with bandwidth and cable length options includes Rohde & Schwarz probe interface and SMA connectors in a soft case, as well as a probe stand tripod.
Order number 1333.0850.02
AC/DC 20 kHz current probe
Order number 1333.0844.02
100 kHz current probe
Order number 1409.8204.02
2 MHZ current probe
Order number 1409.7750K02
10 MHZ current probe
Order number 1409.8210.02
10 MHZ Current probe
Order number 1409.8233.02
100 MHZ current probe
Order number 1409.7766K02
100 MHZ current probe
Order number 1409.7772K02
120 MHz current probe
Order number 1801.4932.02
120 MHz current probe
Order number 1409.7789.02
Power supply for probes
Power supply for R&S®RT-ZC10/20/30/31 probes, +/-12V DC, +/-2.5A
Order number 1800.4700.02
Modular probe amplifier module, 1.5 GHz
Order number 1419.3005.02
Modular probe amplifier module, 3 GHz
Order number 1147.2736.02
E and H near-field probe set
Order number 1326.3641.02
3D probe positioner
3D positionier with central tensioning knob for easy clamping and positioning of probes (span width: 200 mm, clamping range: 15 mm)
Order number 1800.0004.02
Power deskew fixture
Deskew fixture for voltage and current probes for power measurements; includes USB 2.0 cable for power supply
Order number 1801.4803.02
Probe positioner with 2 legs
